Rated current: 6-40A
Rated breaking capacity: 10kA
Sensability: A type, AC Type
Rated residual current: 10/30V 300mA
Rated Current off-time≤0.1s
Tripping time: At least 10ms time delay
Rated Voltage: 230V/400 V;50Hz
Rated residual current: 10/30V 300mA
Sensability: A type, AC Type
Rated breaking capacity: 10kA
Rated current: 6-40A
Tripping characteristic: C characteristic curve
Maximum connected fuse: 100A gl(>10kA)
Anti environment capability: according to IEC1008 standard
IP grade of enclosure: IP40( after installation)
Electrical life: not less than 4000 times on-off operation
Mechanical life: not less than 20000 times on-off operation
Installation methord: IEC standard 35MM din rail
Terminal wire connection: conductor 1-25mm²
| Standard | IEC60898 & IEC61009.1 |
| Rated Voltage(Un) | 230V/400 V;50Hz |
| Rated Current(In) | 6-40A |
| Rated Residual Operating Current | 30,100,300,500mA |
| Rated Current off-time | ≤0.1s |
| Min Value of Rated Operating and Breaking Capacity(Im) | 63A |
| Electrical life | not less than 4000 times |
| Mechanical life | not less than 20000 times |
| Installation | Standard 35mm DIN rail |
